Nominal Pipe Size Chart in mm
Nominal Pipe Size Chart in mm Manufacturer, Supplier, & Exporter in India – Trimac Piping Solutions
Trimac Piping Solutions is one of the largest Pipe manufacturers, Suppliers & Exporters in India. We offer our customers reliable, cost-effective, and high-quality superior Stainless Steel Pipe products according to international specification ASTM and dimensional specification ANSI/ASME Pipe. Extensive capability range, exceptional quality, and unrivalled customer service make Trimac Piping Solutions Pipe Fittings the premiere value solution for all of your Buttweld Fittings needs.
Nominal Pipe Size Chart In Mm, Nominal Pipe Size Chart Pdf, Pipe Size Chart In Mm And Inches, Pipe Size Chart In Mm And Inches PDF
Nominal Pipe Size Chart
| Nominal Pipe Size | Sockolet OD | Body OD | Length Of Thread | Socket Length External | Centre To End – 90′ | Centre To End – 45′ | ||||||||||
| NPS | Ø A | Ø D | E | F | G | G1 | ||||||||||
| # | 2000 | 3000 | 6000 | 2000 | 3000 | 6000 | 2000 | 3000 | 6000 | 2000 | 3000 | 6000 | 2000 | 3000 | 6000 | |
| 1/8″ | 24 | 24 | 26 | 14 | 15 | 21 | 6.7 | 10 | 10 | 14 | 20.6 | 20.6 | 24.6 | 17.5 | 17.5 | 19.1 |
| 1/4″ | 24 | 26 | 34 | 19 | 17 | 24 | 10.2 | 14 | 14 | 17 | 20.6 | 24.6 | 28.4 | 17.5 | 19.1 | 22.4 |
| 38″ | 26 | 34 | 39 | 21 | 21 | 28 | 10.4 | 14 | 14 | 18 | 24.6 | 28.4 | 33.3 | 19.1 | 22.4 | 25.4 |
| 1/2″ | 34 | 39 | 46 | 25 | 24 | 33 | 13.6 | 18 | 18 | 22 | 28.4 | 33.3 | 38.1 | 22.4 | 25.4 | 28.4 |
| 3/4″ | 39 | 46 | 56 | 30 | 30 | 39 | 13.9 | 18 | 19 | 23 | 33.3 | 38.1 | 44.5 | 25.4 | 28.4 | 33.3 |
| 1″ | 47 | 56 | 62 | 36 | 37 | 47 | 17.3 | 22 | 23 | 28 | 38.1 | 44.5 | 50.8 | 28.4 | 33.3 | 35.1 |
| 1 1/4″ | 57 | 62 | 76 | 45 | 46 | 57 | 18 | 22 | 24 | 29 | 44.5 | 50.8 | 60.5 | 33.3 | 35.1 | 42.9 |
| 1 1/2″ | 63 | 76 | 85 | 52 | 53 | 64 | 18.4 | 24 | 24 | 30 | 50.8 | 60.5 | 76.2 | 35.1 | 42.9 | 43.7 |
| 2″ | 77 | 85 | 102 | 64 | 68 | 78 | 19.2 | 24 | 27 | 32 | 60.5 | 63.5 | 82.6 | 42.9 | 43.7 | 52.3 |
| 2 1/2″ | 93 | 102 | 121 | 77 | 79 | 95 | 28.9 | 35 | 37 | 45 | 76.2 | 82.6 | 95.3 | 52.3 | 52.3 | 63.5 |
| 3″ | 111 | 122 | 147 | 94 | 97 | 114 | 30.5 | 37 | 40 | 48 | 85.9 | 95.3 | 106.4 | 63.5 | 63.5 | 79.2 |
| 4″ | 149 | 156 | 154 | 117 | 126 | 142 | 33 | 41 | 45 | 52 | 106.4 | 114.3 | 114.3 | 79.2 | 79.2 | 79.2 |
Nominal Pipe Size Chart – Socket OD
| Nominal Pipe Size | Sockolet OD | Body OD | Length Of Thread | Socket Length External | Centre To End – 90′ | Centre To End – 45′ | ||||||||||
| NPS | Ø A | Ø D | E | F | G | G 1 | ||||||||||
| # | 2000 | 3000 | 6000 | 2000 | 3000 | 6000 | 2000 | 3000 | 6000 | 2000 | 3000 | 6000 | 2000 | 3000 | 6000 | |
| 1/8″ | 24 | 24 | 26 | 14 | 15 | 21 | 6.7 | 10 | 10 | 14 | 20.6 | 20.6 | 24.6 | 17.5 | 17.5 | 19.1 |
| 1/4″ | 24 | 26 | 34 | 19 | 17 | 24 | 10.2 | 14 | 14 | 17 | 20.6 | 24.6 | 28.4 | 17.5 | 19.1 | 22.4 |
| 38″ | 26 | 34 | 39 | 21 | 21 | 28 | 10.4 | 14 | 14 | 18 | 24.6 | 28.4 | 33.3 | 19.1 | 22.4 | 25.4 |
| 1/2″ | 34 | 39 | 46 | 25 | 24 | 33 | 13.6 | 18 | 18 | 22 | 28.4 | 33.3 | 38.1 | 22.4 | 25.4 | 28.4 |
| 3/4″ | 39 | 46 | 56 | 30 | 30 | 39 | 13.9 | 18 | 19 | 23 | 33.3 | 38.1 | 44.5 | 25.4 | 28.4 | 33.3 |
| 1″ | 47 | 56 | 62 | 36 | 37 | 47 | 17.3 | 22 | 23 | 28 | 38.1 | 44.5 | 50.8 | 28.4 | 33.3 | 35.1 |
| 1 1/4″ | 57 | 62 | 76 | 45 | 46 | 57 | 18 | 22 | 24 | 29 | 44.5 | 50.8 | 60.5 | 33.3 | 35.1 | 42.9 |
| 1 1/2″ | 63 | 76 | 85 | 52 | 53 | 64 | 18.4 | 24 | 24 | 30 | 50.8 | 60.5 | 76.2 | 35.1 | 42.9 | 43.7 |
| 2″ | 77 | 85 | 102 | 64 | 68 | 78 | 19.2 | 24 | 27 | 32 | 60.5 | 63.5 | 82.6 | 42.9 | 43.7 | 52.3 |
| 2 1/2″ | 93 | 102 | 121 | 77 | 79 | 95 | 28.9 | 35 | 37 | 45 | 76.2 | 82.6 | 95.3 | 52.3 | 52.3 | 63.5 |
| 3″ | 111 | 122 | 147 | 94 | 97 | 114 | 30.5 | 37 | 40 | 48 | 85.9 | 95.3 | 106.4 | 63.5 | 63.5 | 79.2 |
| 4″ | 149 | 156 | 154 | 117 | 126 | 142 | 33 | 41 | 45 | 52 | 106.4 | 114.3 | 114.3 | 79.2 | 79.2 | 79.2 |
ANSI B16.5 Flanges Applications and Uses
- Stainless Steel Flanges used in Petrochemical Industries
- Stainless Steel Flanges used in Refineries Industries
- Companion Flanges used in Heat Exchangers
- Flanges used in Sugar Industries
- Stainless Steel Lap Joint Flanges used in Chemical Industries
- SS Flanges used in Oil and Gas Industries
- Stainless Steel Flanges used in Pharmaceuticals
- Flanges used in Power Plants
